更新记录

1.1.12(2024-10-31)

新增身份证正反面图片参数,可根据返回参数获取base64图片内容

1.1.11(2024-10-31)

身份证识别新增身份证照片返回参数,具体参数和相关接口见说明文档

1.1.10(2024-10-26)

优化部分手机身份证识别率

查看更多

平台兼容性

Vue2 Vue3
App 快应用 微信小程序 支付宝小程序 百度小程序 字节小程序 QQ小程序
HBuilderX 4.0,Android:5.0,iOS:不确定,HarmonyNext:不确定 × × × × × ×
钉钉小程序 快手小程序 飞书小程序 京东小程序
× × × ×
H5-Safari Android Browser 微信浏览器(Android) QQ浏览器(Android) Chrome IE Edge Firefox PC-Safari
× × × × × × × × ×

更新记录

1.0.0(2024-09-29)

新增插件,OCR功能,能够识别中文文本和英文文本。可以从相机拍照或者从相册选取,文本识别后可以直接返回或者手动从图片中选择。

1.1.0(2024-10-1)

1.修复相机和相册取消问题

2.修复从照片选取内容序号异常问题

3.新增身份证识别功能

1.1.1(2024-10-2)

1.增加身份证识别时的手电筒功能 示例使用


点击右边“使用HBuilderX导入示例项目”,导入后示例中有个PDF文件,按照文件运行项目。

平台兼容性

目前支持Android,CPU类型支持x86,arm64-v8a,armeabi-v7a android目前适配到API 34

插件功能

识别样例

识别样例

身份证识别:

普通文本:

原图:
识别结果(从照片选取,也可以不从照片选取直接返回识别文本)
Block
Line
Symbol

插件使用及相关API说明


在线使用插件通用流程

  1. 购买此插件,选择该插件绑定的项目(使用者项目)。

  2. 购买页面导入到相应项目。

  3. 根据插件作者的提供的文档开发代码,在代码中引用插件,调用插件功能。

  4. 打包自定义基座,得到自定义基座,然后运行时选择自定义基座,进行log输出测试。

  5. 开发完毕后正式云打包。

此插件的使用

引入插件

import {OCROptions,uTSOCRRecognize,getBase64FromFilePath} from "@/uni_modules/xt-ocr-recognize"

使用插件

uniapp x版本:
let options = {
    params: `{
    'recognizeType':1,
    'imgLocation': 0,
    'pickTextFromImg': false,
    'pickTextAreaType': 3,
    'textAreaType':1,
    }`,
    complete: (res : any) => {
        console.log(res);
        let strR:string = res.toString();
    }
} as OCROptions;
uTSOCRRecognize(options);

uniapp版本 请自行适配
大致这样写(自行调试):

uTSOCRRecognize({
    params: '{"recognizeType": 1,"showBeep": true,"imgLocation": 0,"pickTextFromImg": false,"pickTextAreaType": 3,"textAreaType": 1}',
    complete: (res) => {
        console.log(res);
    }
});

获取图片Base64数据接口,用于身份证正反面:

uniapp-x
const that = this;
let options = {
    params: that.fptah,
    complete: (res : any) => {
        console.log("base64 callback");
    }
} as LScanOptions;
getBase64FromFilePath(options);

uniapp
const that = this;
getBase64FromFilePath({
      params: that.fptah,
      complete: (res) => {
         console.log("base64 callback");
      },
});
参数说明
参数名 参数类型 参数默认值 参数说明
recognizeType int 0 如果不是普通文本识别,imgLocation和pickTextFromImg不生效,为默认值,自动返回相应的识别内容,内容格式后面有说明
0 - 普通文本识别
1- 身份证识别正面,返回值JSON格式(身份证号码,姓名,性别,民族,出生,地址,头像的base64)
2 - 身份证识别反面,返回值JSON格式(签发机关,有效期限)
3 - 车牌扫描
4 - 银行卡扫描
...后续根据需求增加
imgLocation Integer 0 识别图片选取方式
0 - camera 相机获取
1 - album 相册获取
pickTextFromImg Boolean False 识别文本是否手动从图片中选择,这个取值受textAreaType和pickTextAreaType影响
True - 返回值手动从已识别的图片上获取,返回值类型为文本,选择区域受pickTextAreaType影响
False - 直接返回结果,返回值是JSON对象,返回值内容受textAreaType影响
textAreaType Integer 0 当pickTextFromImg 为False时,设置该值,文本返回区域类型
0 - block
1 - line
2 - element
3 - symbol
4 - all 数据比较大
具体数据类型会有说明
pickTextAreaType Integer 0 当pickTextFromImg 为True时,设置该值,文本选取区域类型
0 - block
1 - line
2 - element
3 - symbol
回调结果说明
回调结果是一个JSON格式数据,包含两个属性
返回值名称 返回值类型 返回值说明
status String 成功为"success",其他为失败
result String 只有成功时才有,内容为识别结果,结果格式根据pickTextFromImg/textAreaType/pickTextAreaType不同而不同,后面会有说明
result值说明

身份证识别

正面

{
    "status": "success",
    "result": {
        "idNo": "3201xxxxxxxxxxxx",
        "name": "陶xx",
        "sex": "男",
        "birthday": "1962年6月26日",
        "address": "江苏省xxxxxx86号",
        "nation":"汉",
        "base64_face": "iVBORw0KGgoAAAANSUhEUgAAAV4AAAFrCAIAAA",
        "imagePath":"file:\/\/\/storage\/emulated\/0\/Android\/data\/uni.UNIBD81368\/files\/Pictures\/JPEG_20241031_131017_20637315.jpg"
    }
}

获取图片Base64数据接口:
const that = this;
let options = {
    params: that.fptah,
    complete: (res : any) => {
        console.log("base64 callback");
    }
} as LScanOptions;
getBase64FromFilePath(options);

反面

{
    "status": "success",
    "result": {
        "issueOrg": "xxx县公安局",
        "validPeriod": "2007.06.02-2027.06.02",
        "imagePath":"file:\/\/\/storage\/emulated\/0\/Android\/data\/uni.UNIBD81368\/files\/Pictures\/JPEG_20241031_131017_20637315.jpg"
    }
}

获取图片Base64数据接口:
const that = this;
let options = {
    params: that.fptah,
    complete: (res : any) => {
        console.log("base64 callback");
    }
} as LScanOptions;
getBase64FromFilePath(options);

车牌扫描

carType
    蓝牌 0;
    黄牌单层 1;
    白牌单层 2;
    绿牌新能源 3;
    黑牌港澳 4;
    香港单层 5;
    香港双层 6;
    澳门单层 7;
    澳门双层 8;
    黄牌双层 9;

{
    "status": "success",
    "result": {
        "carNumber": "粤xxxxxx",
        "carType": 0
    }
}

普通文本识别图片样例:

pickTextFromImg textAreaType pickTextAreaType JSON数据格式样例
False 0 NA(不生效) 下方0.0
False 1 NA(不生效) 下方0.1
False 2 NA(不生效) 下方0.2
False 3 NA(不生效) 下方0.3
False 4 NA(不生效) 下方0.4
True NA(不生效) 0 下方1.0
True NA(不生效) 1 下方1.1
True NA(不生效) 2 下方1.2
True NA(不生效) 3 下方1.3
0.0
{
    "status": "success",
    "result": {
        "text": "从帐户添加联系人\n从文件导入联系人",
        "blocks": [
            {
                "blockText": "从帐户添加联系人",
                "blockCornerPoints": [
                    {
                        "x": 358,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 204
                    },
                    {
                        "x": 358,
                        "y": 204
                    }
                ],
                "blockBoundingBox": {
                    "left": 358,
                    "top": 160,
                    "right": 724,
                    "bottom": 204
                }
            },
            {
                "blockText": "从文件导入联系人",
                "blockCornerPoints": [
                    {
                        "x": 358,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 374
                    },
                    {
                        "x": 358,
                        "y": 374
                    }
                ],
                "blockBoundingBox": {
                    "left": 358,
                    "top": 330,
                    "right": 723,
                    "bottom": 374
                }
            }
        ]
    }
}
0.1
{
    "status": "success",
    "result": {
        "text": "从帐户添加联系人\n从文件导入联系人",
        "lines": [
            {
                "lineText": "从帐户添加联系人",
                "lineCornerPoints": [
                    {
                        "x": 358,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 204
                    },
                    {
                        "x": 358,
                        "y": 204
                    }
                ],
                "lineBoundingBox": {
                    "left": 358,
                    "top": 160,
                    "right": 724,
                    "bottom": 204
                }
            },
            {
                "lineText": "从文件导入联系人",
                "lineCornerPoints": [
                    {
                        "x": 358,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 374
                    },
                    {
                        "x": 358,
                        "y": 374
                    }
                ],
                "lineBoundingBox": {
                    "left": 358,
                    "top": 330,
                    "right": 723,
                    "bottom": 374
                }
            }
        ]
    }
}
0.2
{
    "status": "success",
    "result": {
        "text": "从帐户添加联系人\n从文件导入联系人",
        "elements": [
            {
                "elementText": "从帐户添加联系人",
                "elementCornerPoints": [
                    {
                        "x": 358,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 204
                    },
                    {
                        "x": 358,
                        "y": 204
                    }
                ],
                "elementBoundingBox": {
                    "left": 358,
                    "top": 160,
                    "right": 724,
                    "bottom": 204
                }
            },
            {
                "elementText": "从文件导入联系人",
                "elementCornerPoints": [
                    {
                        "x": 358,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 374
                    },
                    {
                        "x": 358,
                        "y": 374
                    }
                ],
                "elementBoundingBox": {
                    "left": 358,
                    "top": 330,
                    "right": 723,
                    "bottom": 374
                }
            }
        ]
    }
}
0.3
{
    "status": "success",
    "result": {
        "text": "从帐户添加联系人\n从文件导入联系人",
        "symbols": [
            {
                "symbolText": "从",
                "symbolCornerPoints": [
                    {
                        "x": 358,
                        "y": 160
                    },
                    {
                        "x": 418,
                        "y": 160
                    },
                    {
                        "x": 418,
                        "y": 204
                    },
                    {
                        "x": 358,
                        "y": 204
                    }
                ],
                "symbolBoundingBox": {
                    "left": 358,
                    "top": 160,
                    "right": 418,
                    "bottom": 204
                }
            },
            {
                "symbolText": "帐",
                "symbolCornerPoints": [
                    {
                        "x": 418,
                        "y": 160
                    },
                    {
                        "x": 464,
                        "y": 160
                    },
                    {
                        "x": 464,
                        "y": 204
                    },
                    {
                        "x": 418,
                        "y": 204
                    }
                ],
                "symbolBoundingBox": {
                    "left": 418,
                    "top": 160,
                    "right": 464,
                    "bottom": 204
                }
            },
            {
                "symbolText": "户",
                "symbolCornerPoints": [
                    {
                        "x": 464,
                        "y": 160
                    },
                    {
                        "x": 509,
                        "y": 160
                    },
                    {
                        "x": 509,
                        "y": 204
                    },
                    {
                        "x": 464,
                        "y": 204
                    }
                ],
                "symbolBoundingBox": {
                    "left": 464,
                    "top": 160,
                    "right": 509,
                    "bottom": 204
                }
            },
            {
                "symbolText": "添",
                "symbolCornerPoints": [
                    {
                        "x": 509,
                        "y": 160
                    },
                    {
                        "x": 555,
                        "y": 160
                    },
                    {
                        "x": 555,
                        "y": 204
                    },
                    {
                        "x": 509,
                        "y": 204
                    }
                ],
                "symbolBoundingBox": {
                    "left": 509,
                    "top": 160,
                    "right": 555,
                    "bottom": 204
                }
            },
            {
                "symbolText": "加",
                "symbolCornerPoints": [
                    {
                        "x": 555,
                        "y": 160
                    },
                    {
                        "x": 601,
                        "y": 160
                    },
                    {
                        "x": 601,
                        "y": 204
                    },
                    {
                        "x": 555,
                        "y": 204
                    }
                ],
                "symbolBoundingBox": {
                    "left": 555,
                    "top": 160,
                    "right": 601,
                    "bottom": 204
                }
            },
            {
                "symbolText": "联",
                "symbolCornerPoints": [
                    {
                        "x": 601,
                        "y": 160
                    },
                    {
                        "x": 650,
                        "y": 160
                    },
                    {
                        "x": 650,
                        "y": 204
                    },
                    {
                        "x": 601,
                        "y": 204
                    }
                ],
                "symbolBoundingBox": {
                    "left": 601,
                    "top": 160,
                    "right": 650,
                    "bottom": 204
                }
            },
            {
                "symbolText": "系",
                "symbolCornerPoints": [
                    {
                        "x": 650,
                        "y": 160
                    },
                    {
                        "x": 696,
                        "y": 160
                    },
                    {
                        "x": 696,
                        "y": 204
                    },
                    {
                        "x": 650,
                        "y": 204
                    }
                ],
                "symbolBoundingBox": {
                    "left": 650,
                    "top": 160,
                    "right": 696,
                    "bottom": 204
                }
            },
            {
                "symbolText": "人",
                "symbolCornerPoints": [
                    {
                        "x": 696,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 204
                    },
                    {
                        "x": 696,
                        "y": 204
                    }
                ],
                "symbolBoundingBox": {
                    "left": 696,
                    "top": 160,
                    "right": 724,
                    "bottom": 204
                }
            },
            {
                "symbolText": "从",
                "symbolCornerPoints": [
                    {
                        "x": 358,
                        "y": 330
                    },
                    {
                        "x": 401,
                        "y": 330
                    },
                    {
                        "x": 401,
                        "y": 374
                    },
                    {
                        "x": 358,
                        "y": 374
                    }
                ],
                "symbolBoundingBox": {
                    "left": 358,
                    "top": 330,
                    "right": 401,
                    "bottom": 374
                }
            },
            {
                "symbolText": "文",
                "symbolCornerPoints": [
                    {
                        "x": 404,
                        "y": 330
                    },
                    {
                        "x": 448,
                        "y": 330
                    },
                    {
                        "x": 448,
                        "y": 374
                    },
                    {
                        "x": 404,
                        "y": 374
                    }
                ],
                "symbolBoundingBox": {
                    "left": 404,
                    "top": 330,
                    "right": 448,
                    "bottom": 374
                }
            },
            {
                "symbolText": "件",
                "symbolCornerPoints": [
                    {
                        "x": 450,
                        "y": 330
                    },
                    {
                        "x": 493,
                        "y": 330
                    },
                    {
                        "x": 493,
                        "y": 374
                    },
                    {
                        "x": 450,
                        "y": 374
                    }
                ],
                "symbolBoundingBox": {
                    "left": 450,
                    "top": 330,
                    "right": 493,
                    "bottom": 374
                }
            },
            {
                "symbolText": "导",
                "symbolCornerPoints": [
                    {
                        "x": 497,
                        "y": 330
                    },
                    {
                        "x": 538,
                        "y": 330
                    },
                    {
                        "x": 538,
                        "y": 374
                    },
                    {
                        "x": 497,
                        "y": 374
                    }
                ],
                "symbolBoundingBox": {
                    "left": 497,
                    "top": 330,
                    "right": 538,
                    "bottom": 374
                }
            },
            {
                "symbolText": "入",
                "symbolCornerPoints": [
                    {
                        "x": 542,
                        "y": 330
                    },
                    {
                        "x": 585,
                        "y": 330
                    },
                    {
                        "x": 585,
                        "y": 374
                    },
                    {
                        "x": 542,
                        "y": 374
                    }
                ],
                "symbolBoundingBox": {
                    "left": 542,
                    "top": 330,
                    "right": 585,
                    "bottom": 374
                }
            },
            {
                "symbolText": "联",
                "symbolCornerPoints": [
                    {
                        "x": 588,
                        "y": 330
                    },
                    {
                        "x": 631,
                        "y": 330
                    },
                    {
                        "x": 631,
                        "y": 374
                    },
                    {
                        "x": 588,
                        "y": 374
                    }
                ],
                "symbolBoundingBox": {
                    "left": 588,
                    "top": 330,
                    "right": 631,
                    "bottom": 374
                }
            },
            {
                "symbolText": "系",
                "symbolCornerPoints": [
                    {
                        "x": 635,
                        "y": 330
                    },
                    {
                        "x": 676,
                        "y": 330
                    },
                    {
                        "x": 676,
                        "y": 374
                    },
                    {
                        "x": 635,
                        "y": 374
                    }
                ],
                "symbolBoundingBox": {
                    "left": 635,
                    "top": 330,
                    "right": 676,
                    "bottom": 374
                }
            },
            {
                "symbolText": "人",
                "symbolCornerPoints": [
                    {
                        "x": 680,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 374
                    },
                    {
                        "x": 680,
                        "y": 374
                    }
                ],
                "symbolBoundingBox": {
                    "left": 680,
                    "top": 330,
                    "right": 723,
                    "bottom": 374
                }
            }
        ]
    }
}
0.4
JSON结构,可以用嵌套4个For循环读取
blocks [
    block {
        blockText: block文本
        blockCornerPoints:识别矩形框四个顶点
        blockBoundingBox:识别区域矩形
        lineJSONArray [
            line {
                lineText: line 文本
                lineCornerPoints:识别矩形框四个顶点
                lineBoundingBox:识别区域矩形
                elementJSONArray [
                    element {
                        elementText: element 文本
                        elementCornerPoints:识别矩形框四个顶点
                        elementBoundingBox:识别区域矩形
                        symbolJSONArray [
                            symbol {
                                symbolText: symbol 文本
                                symbolCornerPoints:识别矩形框四个顶点
                                symbolBoundingBox:识别区域矩形
                            }
                        ]
                    }
                ]
            }
        ]
    }
]
{
    "status": "success",
    "result": {
        "text": "从帐户添加联系人\n从文件导入联系人",
        "blocks": [
            {
                "blockText": "从帐户添加联系人",
                "blockCornerPoints": [
                    {
                        "x": 358,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 160
                    },
                    {
                        "x": 724,
                        "y": 204
                    },
                    {
                        "x": 358,
                        "y": 204
                    }
                ],
                "blockBoundingBox": {
                    "left": 358,
                    "top": 160,
                    "right": 724,
                    "bottom": 204
                },
                "lineJSONArray": [
                    {
                        "lineText": "从帐户添加联系人",
                        "lineCornerPoints": [
                            {
                                "x": 358,
                                "y": 160
                            },
                            {
                                "x": 724,
                                "y": 160
                            },
                            {
                                "x": 724,
                                "y": 204
                            },
                            {
                                "x": 358,
                                "y": 204
                            }
                        ],
                        "lineBoundingBox": {
                            "left": 358,
                            "top": 160,
                            "right": 724,
                            "bottom": 204
                        },
                        "elementJSONArray": [
                            {
                                "elementText": "从帐户添加联系人",
                                "elementCornerPoints": [
                                    {
                                        "x": 358,
                                        "y": 160
                                    },
                                    {
                                        "x": 724,
                                        "y": 160
                                    },
                                    {
                                        "x": 724,
                                        "y": 204
                                    },
                                    {
                                        "x": 358,
                                        "y": 204
                                    }
                                ],
                                "elementBoundingBox": {
                                    "left": 358,
                                    "top": 160,
                                    "right": 724,
                                    "bottom": 204
                                },
                                "symbolJSONArray": [
                                    {
                                        "symbolText": "从",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 358,
                                                "y": 160
                                            },
                                            {
                                                "x": 418,
                                                "y": 160
                                            },
                                            {
                                                "x": 418,
                                                "y": 204
                                            },
                                            {
                                                "x": 358,
                                                "y": 204
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 358,
                                            "top": 160,
                                            "right": 418,
                                            "bottom": 204
                                        }
                                    },
                                    {
                                        "symbolText": "帐",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 418,
                                                "y": 160
                                            },
                                            {
                                                "x": 464,
                                                "y": 160
                                            },
                                            {
                                                "x": 464,
                                                "y": 204
                                            },
                                            {
                                                "x": 418,
                                                "y": 204
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 418,
                                            "top": 160,
                                            "right": 464,
                                            "bottom": 204
                                        }
                                    },
                                    {
                                        "symbolText": "户",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 464,
                                                "y": 160
                                            },
                                            {
                                                "x": 509,
                                                "y": 160
                                            },
                                            {
                                                "x": 509,
                                                "y": 204
                                            },
                                            {
                                                "x": 464,
                                                "y": 204
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 464,
                                            "top": 160,
                                            "right": 509,
                                            "bottom": 204
                                        }
                                    },
                                    {
                                        "symbolText": "添",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 509,
                                                "y": 160
                                            },
                                            {
                                                "x": 555,
                                                "y": 160
                                            },
                                            {
                                                "x": 555,
                                                "y": 204
                                            },
                                            {
                                                "x": 509,
                                                "y": 204
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 509,
                                            "top": 160,
                                            "right": 555,
                                            "bottom": 204
                                        }
                                    },
                                    {
                                        "symbolText": "加",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 555,
                                                "y": 160
                                            },
                                            {
                                                "x": 601,
                                                "y": 160
                                            },
                                            {
                                                "x": 601,
                                                "y": 204
                                            },
                                            {
                                                "x": 555,
                                                "y": 204
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 555,
                                            "top": 160,
                                            "right": 601,
                                            "bottom": 204
                                        }
                                    },
                                    {
                                        "symbolText": "联",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 601,
                                                "y": 160
                                            },
                                            {
                                                "x": 650,
                                                "y": 160
                                            },
                                            {
                                                "x": 650,
                                                "y": 204
                                            },
                                            {
                                                "x": 601,
                                                "y": 204
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 601,
                                            "top": 160,
                                            "right": 650,
                                            "bottom": 204
                                        }
                                    },
                                    {
                                        "symbolText": "系",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 650,
                                                "y": 160
                                            },
                                            {
                                                "x": 696,
                                                "y": 160
                                            },
                                            {
                                                "x": 696,
                                                "y": 204
                                            },
                                            {
                                                "x": 650,
                                                "y": 204
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 650,
                                            "top": 160,
                                            "right": 696,
                                            "bottom": 204
                                        }
                                    },
                                    {
                                        "symbolText": "人",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 696,
                                                "y": 160
                                            },
                                            {
                                                "x": 724,
                                                "y": 160
                                            },
                                            {
                                                "x": 724,
                                                "y": 204
                                            },
                                            {
                                                "x": 696,
                                                "y": 204
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 696,
                                            "top": 160,
                                            "right": 724,
                                            "bottom": 204
                                        }
                                    }
                                ]
                            }
                        ]
                    }
                ]
            },
            {
                "blockText": "从文件导入联系人",
                "blockCornerPoints": [
                    {
                        "x": 358,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 330
                    },
                    {
                        "x": 723,
                        "y": 374
                    },
                    {
                        "x": 358,
                        "y": 374
                    }
                ],
                "blockBoundingBox": {
                    "left": 358,
                    "top": 330,
                    "right": 723,
                    "bottom": 374
                },
                "lineJSONArray": [
                    {
                        "lineText": "从文件导入联系人",
                        "lineCornerPoints": [
                            {
                                "x": 358,
                                "y": 330
                            },
                            {
                                "x": 723,
                                "y": 330
                            },
                            {
                                "x": 723,
                                "y": 374
                            },
                            {
                                "x": 358,
                                "y": 374
                            }
                        ],
                        "lineBoundingBox": {
                            "left": 358,
                            "top": 330,
                            "right": 723,
                            "bottom": 374
                        },
                        "elementJSONArray": [
                            {
                                "elementText": "从文件导入联系人",
                                "elementCornerPoints": [
                                    {
                                        "x": 358,
                                        "y": 330
                                    },
                                    {
                                        "x": 723,
                                        "y": 330
                                    },
                                    {
                                        "x": 723,
                                        "y": 374
                                    },
                                    {
                                        "x": 358,
                                        "y": 374
                                    }
                                ],
                                "elementBoundingBox": {
                                    "left": 358,
                                    "top": 330,
                                    "right": 723,
                                    "bottom": 374
                                },
                                "symbolJSONArray": [
                                    {
                                        "symbolText": "从",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 358,
                                                "y": 330
                                            },
                                            {
                                                "x": 401,
                                                "y": 330
                                            },
                                            {
                                                "x": 401,
                                                "y": 374
                                            },
                                            {
                                                "x": 358,
                                                "y": 374
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 358,
                                            "top": 330,
                                            "right": 401,
                                            "bottom": 374
                                        }
                                    },
                                    {
                                        "symbolText": "文",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 404,
                                                "y": 330
                                            },
                                            {
                                                "x": 448,
                                                "y": 330
                                            },
                                            {
                                                "x": 448,
                                                "y": 374
                                            },
                                            {
                                                "x": 404,
                                                "y": 374
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 404,
                                            "top": 330,
                                            "right": 448,
                                            "bottom": 374
                                        }
                                    },
                                    {
                                        "symbolText": "件",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 450,
                                                "y": 330
                                            },
                                            {
                                                "x": 493,
                                                "y": 330
                                            },
                                            {
                                                "x": 493,
                                                "y": 374
                                            },
                                            {
                                                "x": 450,
                                                "y": 374
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 450,
                                            "top": 330,
                                            "right": 493,
                                            "bottom": 374
                                        }
                                    },
                                    {
                                        "symbolText": "导",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 497,
                                                "y": 330
                                            },
                                            {
                                                "x": 538,
                                                "y": 330
                                            },
                                            {
                                                "x": 538,
                                                "y": 374
                                            },
                                            {
                                                "x": 497,
                                                "y": 374
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 497,
                                            "top": 330,
                                            "right": 538,
                                            "bottom": 374
                                        }
                                    },
                                    {
                                        "symbolText": "入",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 542,
                                                "y": 330
                                            },
                                            {
                                                "x": 585,
                                                "y": 330
                                            },
                                            {
                                                "x": 585,
                                                "y": 374
                                            },
                                            {
                                                "x": 542,
                                                "y": 374
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 542,
                                            "top": 330,
                                            "right": 585,
                                            "bottom": 374
                                        }
                                    },
                                    {
                                        "symbolText": "联",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 588,
                                                "y": 330
                                            },
                                            {
                                                "x": 631,
                                                "y": 330
                                            },
                                            {
                                                "x": 631,
                                                "y": 374
                                            },
                                            {
                                                "x": 588,
                                                "y": 374
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 588,
                                            "top": 330,
                                            "right": 631,
                                            "bottom": 374
                                        }
                                    },
                                    {
                                        "symbolText": "系",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 635,
                                                "y": 330
                                            },
                                            {
                                                "x": 676,
                                                "y": 330
                                            },
                                            {
                                                "x": 676,
                                                "y": 374
                                            },
                                            {
                                                "x": 635,
                                                "y": 374
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 635,
                                            "top": 330,
                                            "right": 676,
                                            "bottom": 374
                                        }
                                    },
                                    {
                                        "symbolText": "人",
                                        "symbolCornerPoints": [
                                            {
                                                "x": 680,
                                                "y": 330
                                            },
                                            {
                                                "x": 723,
                                                "y": 330
                                            },
                                            {
                                                "x": 723,
                                                "y": 374
                                            },
                                            {
                                                "x": 680,
                                                "y": 374
                                            }
                                        ],
                                        "symbolBoundingBox": {
                                            "left": 680,
                                            "top": 330,
                                            "right": 723,
                                            "bottom": 374
                                        }
                                    }
                                ]
                            }
                        ]
                    }
                ]
            }
        ]
    }
}
1.0 按照选取次序为 1,2,3...
{
    "status": "success",
    "result": {
        "1": "从帐户添加联系人",
        "2": "从文件导入联系人"
    }
}
1.1按照选取次序为 1,2,3...
{
    "status": "success",
    "result": {
        "1": "从帐户添加联系人",
        "2": "从文件导入联系人"
    }
}
1.2按照选取次序为 1,2,3...
{
    "status": "success",
    "result": {
        "1": "从帐户添加联系人",
        "2": "从文件导入联系人"
    }
}
1.3按照选取次序为 1,2,3...
{
    "status": "success",
    "result": {
        "1": "从",
        "2": "户",
        "3": "联",
        "4": "从",
        "5": "导"
    }
}

隐私、权限声明

1. 本插件需要申请的系统权限列表:

<uses-permission android:name="android.permission.CAMERA" /> <uses-permission android:name="android.permission.VIBRATE" /> <uses-permission android:name="android.permission.FLASHLIGHT" /> <uses-permission android:name="android.permission.READ_EXTERNAL_STORAGE" /> <uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE" /> <uses-permission android:name="android.permission.READ_MEDIA_IMAGES" /> <uses-permission android:name="android.permission.READ_MEDIA_VIDEO" />

2. 本插件采集的数据、发送的服务器地址、以及数据用途说明:

没有数据发服务器.

3. 本插件是否包含广告,如包含需详细说明广告表达方式、展示频率:

没有广告

使用中有什么不明白的地方,就向插件作者提问吧~ 我要提问
